ASUS Prime B760‑PLUS D4 Motherboard (DDR4, PCIe 5.0, ATX)

Perfect for mainstream Intel builds, the Prime B760‑PLUS D4 offers powerful connectivity and compatibility with Intel 12th, 13th, and 14th Gen processors via the LGA 1700 socket. Featuring DDR4 memory support, PCIe 5.0 graphics, and robust storage options, this ATX board blends performance and practicality.

✅ Key Features:

• CPU Socket: LGA 1700 – Intel 12th / 13th / 14th Gen support

• Memory: 4× DDR4 DIMM slots, up to 128 GB, support for OC up to DDR4‑5066+ (XMP)

• Expansion Slots:

  • 1× PCIe 5.0 x16 (SafeSlot Core+)

  • 1× PCIe 4.0 x16 (x4 mode)

  • 2× PCIe 3.0 x1

• Storage: 3× M.2 PCIe 4.0 slots (Gen4 x4, x4, x2), plus 4× SATA 6 Gb/s ports (RAID 0/1/5/10 support)

• Networking: Realtek 2.5 Gb Ethernet with LANGuard; built-in Wi-Fi not included

• USB Ports: USB 3.2 Gen 2×2 Type‑C (rear), USB 3.2 Gen 1 Type‑C (front header), USB 3.2 Gen2, Gen1, and USB 2.0 ports; USB4/Thunderbolt header supported

• Display Outputs: HDMI 2.1, DisplayPort 1.4, VGA (4K@60Hz support)

• Audio: Realtek 7.1-channel HD audio codec

• Cooling & Control: VRM, M.2, and PCH heatsinks; hybrid fan headers; ASUS Fan Xpert 2+; Aura Sync RGB headers; OptiMem II memory routing

• Form Factor: ATX (305 x 244 mm)
